Description
OMG X4 SERIES POLARIS DR160A Brushless ESC – Black
Feature:
- Specifically designed for the highest level of spec and mod 1:10 racing and drifting cars.
- 32-bit microprocessor with more powerful processing capability and more accurate motor output.
- Full aluminum case with highly efficient heat dissipation system and strong current resistance capability.
- Plenty of adjustable parameters supports most types of racing.
- The ESC has a built-in maximum BEC output current of 10A. The output voltage is adjustable at 6.0V/7.4V, easily meeting various powerful servos and high-voltage servos.
- With Real-time data recording function, which supports real-time checking of ESC maximum temperature, motor speed, voltage, timing and other datas.
- New software design with ultra-smooth startup and precise throttle linearity.
- Bluetooth module is connected to adjust parameters and upgrade software through the mobile APP (Supports real-time parameter adjustment, no need to restart the ESC.)
- Multiple protections: high-voltage protection, low-voltage protection, throttle signal loss protection, stall protection and over-temperature protection
- *Programmable with OMG POLARIS Bluetooth Program Module (sold separately)
Specification:
- Sensored brushless ESC
- Cont. Current: 160A
- Max Current: 720A
- Supported Motor Type: Sensored Brushless Motors
- Supported Voltage: 2S/3S LiPo
- BEC Output: 6V/7.4V adjustable/4A
- Firmware Online Upgrade: Supported
- Motor Wire: 12AWG 160mm
- Power Wire: 12AWG 160mm
- Dimension：37 x 38 x 31.5mm
- Weight：101g
What is included:
- OMG X4 SERIES POLARIS DR160A Brushless ESC – Black (1 pc)
- Instruction
