OMG X3 SERIES POLARIS DR120A Brushless ESC – Black
Feature:
- This ESC is specially made with focus on 1:10 drift cars and on road racing. New STOCK version (Professional Competiton version) for adjustable Turbo and Boost Timing.
- Aluminum metal case with precise CNC engraving. Unique heatsink slot design for better heat dissipation performance.
- One-piece electronic power switch and setting button.
- Programmable dynamic Turbo and Boost Timing
- Powerful throttle and brake adjustment functions
- Multiple Protection: Low voltage protection, motor and ESC overheat protection, and throttle out of control protection.
- Programmable with OMG POLARIS DR120A/3.0 Program Card (sold separately)
Specification:
- Sensored brushless ESC
- Cont. Current: 120A
- Max Current: 720A
- Supported Motor Type: Sensored Brushless Motors
- Supported Voltage: 2S/3S LiPo
- BEC Output: 6-5V/3-5A Linear regulator mode
- Fan: 5V@0.16A, Max: 13V (Direct voltage from battery without DC regulating)
- Motor Wire: 12 AWG
- Battery Wire: 12 AWG
- Dimension：41 x 39 x 32mm (w/ Fan)
- Weight：112g
What is included:
- OMG X3 SERIES POLARIS DR120A Brushless ESC – Black (1 pc)
- OMG ESC Fan w/ Alum. Fan Cover (1 set)
- Wires (1 set)
- Instruction
