Description
Acuvance XARVIS XX ESC – Purple
Feature:
- Equipped with the industry’s highest performance high-performance FET device
- Battery reverse connection protection circuit and “alert LED” for reversed polarity connection
- Equipped with BEC voltage switching (6.0 / 7.4V) function
- Two dedicated terminals for various cooling FANs (including FLEDGE FANs)
- Reconstruction of Acuvance original 3D bridge (FAN floating installation) structure
- New capacitor mounting terminal
- XARVIS XX original setting items will be added at any time by installing a new program control circuit
- Fine setting adjustable by TAO III Smart Access (sold separately)
- Compatible with wireless communication by FUTABA S.BUS compatible transmitter (update required)
- Correspond to setting change by Ne-St (sold separately)
- Non-boost / non-turbo status can be viewed with LED
Specification:
- Colour: Purple
- Power supply: 6.0V to 8.5V
- Continuous / momentary maximum current: Up to the maximum current generated by the battery
- Applicable motor: Sensored brushless motor *No limit on number of turns (when boost / turbo is disabled)
- Cable size: AWG 12 (12 gauge)
- Dimensions: 30.5(W) × 35.0(D) × 20.5(H)mm (excluding protrusions)
- Weight (ESC main unit): 47.2g
- Regulator for receiver / servo: 6.0V / 5A or 7.4V / 5A output
What is included:
- Acuvance XARVIS XX ESC – Purple (1 pc)
- Instruction Manual (1 pc)
